Storage & Operation requirements
Working Environment Temperature	0~40℃
Working Environment Humidity	<70%
Storage Temperature	-10~60℃



OPTICAL CHARACTER
Output Power	20 W
Wavelength	1060 - 1080 nm
Beam Quality M²	<1.5
Max. Pulse Energy	0.8 mJ
Repetition Rate	1 - 3000 kHz
Pulse Width	2 - 500 ns
Beam Diameter	5.5~8.5 mm (4σ)
Laser Switching ON/OFF Time	<20 μs
Power Instability (RMS)	<5 %
Power Turning Range	0 - 100 %
Delivery cable length	2 m
MECHANICAL CHARACTER
Laser Dimension (H X W x D)	69 mm x 210 mm x 269 mm
Weight	<4.5 Kg
Cooling Method	Air cooling
ELECTRONIC CHARACTER
Supply Voltage	24 VDC
Power Consumption	<120 W
Recommended Power Supply	≧150 W
Control Interface	RS232 / DB25
